Linksys wrt54g

The original WRT54G was first released in December 2002. It has a 4+1 port network switch (the Internet/WAN port is part of the same internal network switch, but on a different VLAN). The devices have two removable antennas connected through Reverse Polarity TNCconnectors. The WRT54GC router is an exception and has an internal antenna with optional external antenna. As a cost-cutting measure, the design of the latest version of the WRT54G no longer has detachable antennas or TNC connectors. Instead, version 8 routers simply route thin wires into antenna 'shells' eliminating the connector. As a result, Linksys HGA7T and similar external antennas are no longer compatible with this model. Until version 5^[1] WRT54G shipped with Linux based firmware
